MotoGP 2024
Repsol Honda Team

RC213V

The basic concept of the RC213V continues as has been applied since its introduction in 2012, but with some updates for the new season...

RC213V

Technical Specification

Overall length (mm)

2052

Overall width (mm)

645

Overall height (mm)

1,110

Wheelbase (mm)

1,435

Road clearance

115

Weight (kg)

As per FIM regulations

Engine type

liquid-cooled, four-stroke, DOHC 4 valve, V-4

Displacement

1000

Maximum power

Over 180 KW

Frame type

Aluminum twin-tube

Wheels Front (inch)

17

Wheels Rear (inch)

17

Suspension Front

Telescopic fork

Suspension Rear

Pro-link

Fuel tank capacity (litres)

22

Chassis

2024 sees the chassis of the RC213V modified in a variety of ways to improve the balance between turning and stability, aiming to take the most advantage from the engine and the Michelin tyres. The twin-spar aluminium chassis is light and yet provides the stiffness and strength characteristics required to deliver the impressive power from the RC213V’s engine to and through the rear wheel. As well as strength, the frame features the right amount of carefully calibrated flexibility to maximise tyre grip.

Engine

The RC213V’s engine has a capacity of 1000cc and is designed to exploit the maximum power output while remaining durable enough to last the entirety of the season – 21 races and 21 sprint in 2024. Evolution for 2024 has continued and a number of improvements have been made to improve overall performance. The 2024 version of the engine continues advancements made in previous years to improve acceleration and top speed while continuing to reduce weight.

Suspension

Ohlins continue to be fitted to the Honda RC213V, front and rear, in 2023. Suspension provides the crucial link between the wheel, chassis and rider as it is tasked with keeping the tyre in contact with the ground and maintaining the maximum amount of grip over the racetrack. It’s a crucial link in the performance chain and for this reason both Repsol Honda Team riders have a dedicated Ohlins technician assigned to him. Working closely together, HRC and Ohlins are continually looking to make improvements.

Bodywork

The bodywork of MotoGP machines plays an important role in their performance, especially in recent years with the increased usage of ‘winglets’. These aerodynamic appendages help in several areas as HRC engineers seek to extract the maximum performance from the RC213V. Each year the bodywork and aerodynamic changes are some of the most instantly recognisable on the bike.

Tyres

MotoGP tyres are supplied exclusively by Michelin. Each round presents a new challenge for the tyre supplier due to the track layouts and surface of the circuit.

Brakes

Carbon fibre front brakes are provided by Brembo. These carbon brakes produce incredible stopping power and helping in creating some fantastic images of riders entering a corner on just the front wheel as they push to the limit. Wet conditions see some riders continue to use the carbon brakes while others opt to use steel brake disks which can operate at a lower temperature. In both wet and dry conditions, external covers and cooling ducts are sometimes added to help regulate the temperature of the brakes.
